通風管道是通風和空氣調節體系的主要組成有些，它把通風、空調體系的進風口，空氣的熱、濕及凈化處理設備，送(排)風口、部件和風機連變成一個全體，使之有用運轉。下面來針對
濟南通風管道加工的相關知識進行介紹。
Ventilation ducts are the main components of the ventilation and air conditioning system. They connect the air inlets of the ventilation and air conditioning system, the heat, humidity and purification treatment equipment of the air, the air supply (exhaust) outlets, components and fans into a whole to make them work effectively. Next, we will introduce the relevant knowledge of Jinan ventilation pipe processing.
通風管道的規劃使命，便是要合理地安排空氣活動，在確保運用作用的前提下，使工程初投資和運轉維護費用省。因而，通風管道規劃是不是合理，直接影響到全部通風、空氣調節工程締造和運用的技能經濟作用.由此可見，統籌思考通風管道規劃中的各種疑問足十分主要的。
The planning mission of the ventilation duct is to reasonably arrange air activities, and save the initial investment and operation and maintenance costs of the project on the premise of ensuring the use role. Therefore, whether the ventilation duct planning is reasonable or not directly affects the technical and economic effects of the creation and application of all ventilation and air conditioning projects. It can be seen that it is very important to comprehensively consider various questions in the ventilation duct planning.
基本要求：
Basic requirements:
1.把握通風管道內活動阻力(沖突阻力和有些阻力)的核算辦法和壓力散布規則;
1. Grasp the calculation method and pressure dispersion rules of the activity resistance (conflict resistance and some resistance) in the ventilation pipe;
2.熟練把握比摩阻、典型有些構件的有些阻力系數的斷定辦法;
2. Master the determination methods of specific friction and some resistance coefficients of typical components;
3.把握均勻送風管道規劃核算的原理和辦法;
3. Grasp the principles and methods of planning and accounting of uniform air supply pipeline;
4.把握風管的安置和挑選;
4. Grasp the placement and selection of air ducts;
5.了解氣力輸送體系的管道核算和氣一固兩相流的阻力特性;
5. Understand the pipeline accounting of pneumatic conveying system and the resistance characteristics of gas-solid two-phase flow;
6.能斷定風管體系中風機的作業點。
6. Be able to determine the operation point of the fan in the air duct system.
風管內空氣活動的阻力
Resistance of air movement in air duct
空氣沿風管活動的阻力有兩種，一種是因?yàn)榭諝庾陨淼恼硿约捌浜凸鼙谥g的沖突而發生的沿程能量丟失，稱為沖突阻力或沿程阻力;另一種是空氣在流經風管中的管件和設備時，因?yàn)榱魉俚木藜?xì)或方向改變及隨之發生的渦流形成對比集中的能量丟失，稱為有些阻力。
There are two kinds of resistance of air movement along the air duct. One is the energy loss along the air due to the viscosity of the air itself and the conflict between the air and the pipe wall, which is called the conflict resistance or the resistance along the air duct; The other is that when the air flows through the pipe fittings and equipment in the air duct, the energy loss is relatively concentrated due to the change of the flow velocity or direction and the subsequent vortex, which is called some resistance.
依據流體力學原理，空氣沿任何斷面不變的直管活動時，沖突阻力可按下式核算：
According to the principle of fluid mechanics, when the air moves along the straight pipe with any section unchanged, the conflict resistance can be calculated according to the following formula:
沖突阻力系數入與風管內空氣的活動狀況和管壁的粗糙度有關.在通風和空調體系中，薄鋼板風管的空氣活動狀況大多歸于紊流潤滑區到粗糙區之間的過渡區.通常，即便高速風管的活動狀況也處于過渡區.只需風管直徑很小，外表粗糙的磚，混凝土風管內的活動狀況才歸于粗糙區。
The conflict resistance coefficient is related to the air movement in the duct and the roughness of the duct wall In the ventilation and air conditioning system, the air activity of the thin steel duct is mostly attributed to the transition zone between the turbulent lubrication zone and the rough zone. Generally, even the activity of the high-speed duct is in the transition zone Only the bricks and concrete air ducts with small diameter and rough appearance can be classified as rough areas.
The introduction of relevant knowledge of ventilation pipe processing is here. If you have any questions about this, please come to our website http://m.yiruizhoucheng.com Consult and understand.
